Fusion EL-Series

In the box

• One pair of speakers

• 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))

• Two 20 ft (6 meter) speaker cables

• Documentation

Technical specs

• Product code: EL-F651W

• Physical dimensions (Diameter x Depth): 176 x 59 mm (6.93" x 2.32")

• Water and dust rating: IP65

• Configuration: Full range

• Speaker size: 6.5"

• Peak power: 80 W

• RMS power: 20 W

• Sensitivity (1 W / 1 m): 88 dB

• Frequency response: 45 Hz–16 kHz

• Nominal impedance: 4 ohms

• Recommended amplifier power (RMS): 20–40 W/Ch

• Operating temperature range: 0° to 50° C (32° to 122° F)

• Voice coil diameter: 0.79"

• Cone material: Polypropylene cone with cloth surround

• Compass-safe distance: 254 cm (100")

• Warranty: 1 year

Mounting Dimensions

• Mounting diameter clearance: 130 mm (5.12")

• Mounting depth clearance: 43 mm (1.69")

• Frontal grille protrusion: 19 mm (0.75")
